KTR-1000 High-end Lead free relow soldering equipment
Features:
1. Reinforced main hanging bracket to guarantee there is no deforming and board jamming occurred.
2. The dual-rails conveyor is able to improve the production efficiency as well as power & cost.
3. 15% heat transferring efficiency was improved to deal with the lead free process with more complicated and larger products.
4. New cooling configuration to make the filtered or reclaimed air back to oven chamber, it reduced the thermal loss as well as get better flux reclamation.
5. The new two-stage flux recovery system, multi-point collection, fully improves recovery efficiency and reduces maintenance time and frequency for customers.
|
Model |
KTR-1000 |
Control |
Industrial computer |
|
Heating zones quantity |
Top 10, bottom 10 |
Cooling zones quantity |
Top 3, bottom 3 |
|
Heating zone length |
3892mm |
Current plate |
Thick copper plate |
|
Weight |
Approx.:3060Kg |
Dimension |
6300*1430*1530mm |
|
Exhaust capacity |
10㎡/min×2 |
Color |
Grey |
|
Control system |
|||
|
Electricity supply |
3P 380V/220V 50/60HZ |
Temp. control range |
Room temp.～300℃ |
|
Total power |
83KW |
Temp. control accuracy |
±1℃（static state） |
|
Start power |
38KW |
Temp. control method |
PID +SSR drive |
|
Consumption power |
11KW |
PCB temperature deviation |
±1.5℃ |
|
Speed control |
3 sections with 3 inverters |
Data save |
All profiles can be saved |
|
Warm up time |
Approx.30minute |
Abnormal alarm |
High, low temp. alarm |
|
Conveying system |
|||
|
Rail structure |
2 Sectional structure |
Rail fixed method |
Front fix |
|
Chain |
Stuck-free type |
Conveying height |
900±20mm |
|
PCB Max. width |
50-400mm |
Conveying method |
Chain+ belt mesh |
|
Component height |
Top/bottom 30mm |
Conveying speed |
300-2000mm |
|
Conveying direction |
Left to right |
Lubrication |
Automatic |
|
Cooling system |
|||
|
Cooling method |
Water Chiller |
||
|
Heating features |
|||
|
Heating zones |
Top 10,bottom 10（3892mm）can meet the need of the peak lead-free technique. |
||
|
Cooling zones |
After cool down by air, PCB temp. is ≤45℃ at the exit. |
||
|
Warm up time |
From the normal temp. to set temp, approximate 30 minutes. |
||
|
Warm up sequence |
Warm up from two side, save the power and time |
||
|
Profile transfer time |
＜15min |
||
|
Heating zone temp. control accuracy |
±1℃ |
||
|
PCB temp. deviation |
±1.5℃ |
||
|
Empty→ full load heat balance respond time |
≤20 s |
||
