6 zones lead free reflow soldering oven
1.Heating part adopts good quality heating motor from Taiwan, make sure the whole system stability and reliability.
2.Combining with the temperature controller special PID fuzzy control function, change has been monitoring the outside temperature and heat value, the minimum pulse control heating device, fast response, to ensure the precise control of temperature, minimum error temperature distribution in the length direction of the temperature distribution in accordance with IPC standard.
3.It has the functions of temperature difference, fault diagnosis, acousto-optic alarm.
4.Independent microcirculation fan design, up and bottom heating, good thermal compensation, high thermal efficiency, energy saving, fast heating speed, suitable for soldering good quality with BGA and CSP components.The special structure of forced hot air circulation system,which make sure the PCB and components uniform heating, high efficiency, fast heating speed.Adopt Taiwan high temperature motor direct drive hot air circulation, good uniformity, smooth operation, long service life, low noise, small vibration
5.The transmission system adopts China joint venture motor, PID full closed loop speed regulation, and 1:150 imported turbine reducer. It runs smoothly and has adjustable speed range from 0 to 2000 mm / min.
6.Adopt independent wheel structure, topping support and stainless steel mesh belt, machine running stable, accurate speed can reach 1mm/min, especially for BGA/CSP and 0201 welding etc..
7.The protection function of the time delay switch machine is uniform and the temperature is lowered after shutdown, which effectively prevents deformation of components caused by uneven cooling.
Specification
|
model |
LK-600A |
|
heating zones |
up 6/bottom 6 |
|
heating length |
2400MM |
|
heating method |
Up hot air+ bottom IR |
|
cooling zones |
1 |
|
pcb max size |
400MM |
|
transport direction |
L→R |
|
transport height |
880±20mm |
|
transport method |
mesh |
|
transportation speed |
0-1500mm/min |
|
power supply |
5 Line 3 Phase 380V 50/60Hz |
|
Starting power |
16kw |
|
Normal working power |
2KW-3KW |
|
warming-up time |
About 30 mins |
|
range of temperature |
Room tempt.～300℃ |
|
Temperature control method |
RKC400＋PID |
|
Temperature control precision |
±2℃ |
|
Temperature distribution deviation of PCB |
±2℃ |
|
Abnormal alarm |
Abnormal tempt. |
|
Size |
3600×750×1280 |
|
weight |
450KG |
customer factory
Our reflow oven factory
Machine ready for shipping
Wooden package
