2.4m DIP insert line conveyor machine before wave solder

name: insert line

length: 2.4m or 3m

pcb size: 50-300mm

speed: 0.2-2m/min

Product description: DIP insert line, insert conveyor, tht line, dip insertion line, through-hole line, smt line, smd line, smt machine, smd machine, inserting line, THT inserting line, DIP inserting line, inserting conve

2.4m/3M DIP insert line conveyor machine before wave solder

DIP inserting line

DIP Insert Line Features:

1. this machine is used for the PCB board plug-in components for the assembly, it is used in front of wave soldering machine;

2. we can add tracheal tube, gas tube and other equipments;

3. this machine is made of aluminum which sized in 40*40mm.

4. the chain conveyor is smooth and reliable.

5. we can handle the speed by stepless frequency.

Technical parameters:

PCB size: 50-300mm line length: 2.4/3m per phase

Speed: 0.2-2m/min Drive power: 60W AC220V/1phase/50HZ 60w

Tech-Specifications of insertion line

this dip line/dip assembly line is to insert the components on PCB or assembly CFL .

1.Working place arranged at one side beside the conveyor.

2.Motor running ,Chain moving .

3.Our normal length is 12m ,one working place per 1 meter,totally 12 working places

4.Line width is about 900mm ,total height about 1600mm ,working height 740mm.

5.Materials :stainless steel and aluminum .

6.Suitable PCB width 35-300mm width can adjustable.

7.fix 40 W fluorescent tube per working place ,totally 12 tubes.

8.each working place install component box fixtures /boards .

9.Moving method ; Driven by motor ,PLC control ,speed 0.3-3m/min adjustable.

10. Total Power : about 1.1kw ,220V/single phase ,50Hz

11.By connected the line to wave soldering machine with conveyer , it will automatically go to the next step for soldering .
